High Capacity Lithium Battery for UAV 6S 12S 14S from 12000mAh to 38000mAh

Quick details:

Lithium Battery 6S

Capacity: 22000mAh

Discharge rate: 25C

Connector:: AS150

Specification:

Battery connector

Balance charging connector

XT60 / XT90 / AS150

Capacity characteristics of lithium-ion batteries

The capacity test obtains the relationship between the discharge voltage and the capacity of the lithium-ion battery at different rates. The voltage of the lithium-ion battery during the entire discharge process can be divided into 3 stages:

1) The terminal voltage of lithium-ion battery drops rapidly in the initial stage, the greater the discharge rate, the faster the voltage drop;

2) The battery voltage enters a stage of slow change. This period of time is called the platform area of the battery. The smaller the discharge rate, the longer the platform area lasts. The higher the platform voltage, the slower the voltage drop. In the actual use of lithium-ion batteries, it is best to hope that the batteries work in the platform area;

3) When the battery is nearly discharged, the battery load voltage begins to drop sharply until it reaches the discharge cut-off voltage.

The discharge current of a lithium-ion battery will directly affect the actual capacity of the battery. The greater the discharge current, the corresponding decrease in battery capacity, which indicates that the greater the discharge current, the shorter the time to reach the termination voltage. So when talking about battery capacity, you should specify its discharge current (discharge rate).
