NEWLANDLE TECHNOLOGY CO.,LTD Professional Industrial Grade Drone Supplier
5 Years
| Ask Lasest Price | |
| Brand Name : | NLD |
| Model Number : | NIC-GB100 |
| Certification : | ISO9001 CE FCC |
| Price : | Negotible |
| Payment Terms : | L/C, T/T, D/P, D/A |
| Supply Ability : | 100sets/month |
| Delivery Time : | 20days |
Max Payload 100kgs Hybrid Power Drone for Long Rang Cargo Transportation 32kw Water Cooling Engine System
Gasoline Battery Hybrid Power
| Output voltage | DC310V (14S LI-OH battery) |
| Maximum output power | 32KW |
| Battery | 14S LI-ION 30000MAH 30C |
| Charging current | 50A |
| Engine | Two cylinder two stroke 582CC engine |
| Engine speed | 4000RMP~7500RPM |
| Fuel specifications | 92 # gasoline+oil blends(40:1) |
| Fuel consumption | 40L/H(32KW Run continuously) |
| Size | 1000*450*500MM |
| Weight | 60KG(Including host, control circuit and water tank, excluding oil tank) |
| Start launch | Built-in electric |
| Control way | Intelligent frequency conversion |
| Working temperature | -10℃~50℃ |
Comparison of advantages
| Gasoline Battery Hybrid Power | Pure lithium battery system | |
| Capacity | Gasoline energy density is as high as 12KWH/KG, and with a high power-to-weight ratio (power: weight>1) engine, the load capacity is greatly increased when the system power is increased. | The energy density of high lithium battery can only reach 0.2KWH/KG. When the system power is increased, its own weight will increase significantly, and the load capacity will increase slightly. |
| Endurance | Gasoline has high energy density, replacing part of the load with gasoline can greatly extend the battery life or mileage, and is not affected by low temperatur | Lithium batteries have low energy density, their own weight increases greatly when the battery capacity is increased, and the increase in battery life is small, and the battery capacity decreases significantly at low temperatures. |
| Efficiency | The large load means that each aircraft can work on a larger area, reduce the waste of ineffective travel, and refuel and leave to meet the needs of high-intensity continuous dispatch | The load capacity is small, frequent rises and falls, and the battery pack needs to be continuously disassembled and assembled. However, the charging time of the battery pack is too long, and a large number of battery packs need to be rotated. The continuous operation pressure is high and the efficiency is low. |
| Cost | High operating efficiency means that the average operating labor cost is low, and the cost can be reduced. | Field work requires large generators, as well as gasoline. The number of battery recharges has a life limit, and the battery can only be re-purchased and replaced at the expiration date, and the cost is high. |
Performance parameter
| NIC-GB100 | |
| Rotor | 6 |
| Max take-off weight | 100kgs |
| Endurance | 15~120minutes |
| Power system | 1set 32 kw |
| Fuel oil | 92 # gasoline+oil blends(40:1) |
| Fuel consumption | 20L/h |
| Expanded size | 4000x3500x2200mm |
| Folded size | 2000x1750x2200mm |
APP Ground Workstation
1. Android mobile phone ground workstation, Control and adjust drone’s flying parameter, provide google map, check FPV video.
2. Support hand held GPS dot device,RTK dot device,Drone GPS dot and Map for choosing, set up Automatic, semi-automatic AB working mode, flying height, spray mode, flight line spacing, flying speed, Terrain following, automatic obstacle avoidance, course adjustment, fail-sail back.
3. Query job record, flight time, spray width, dose etc.
|
|
