NIA-410 Industrial Drone For Inspection Surveillance Search With Camera

NIA-410 Product Parameters

• Wheelbase: 1000mm
• Size: 800*800*500mm
• Rack weight: 3.5kg
• Rack + power weight: 6.5kg
• Maximum take-off weight: 16kg
• Effective load: 1-5kg
• Motor: 6215 180kv
• Paddle: 24x8.5 inch
• ESC: 80A FOC
• Supply voltage: 12S
• Power set weight: 0.76kg
• Recommended single-axis load: 4-5kg

NIA-410 quad rotor industry drone is suitable for smart cities, police safety, road traffic, environmental protection and water conservancy, power line inspection, emergency rescue, oil pipeline inspection, surveying and other fields.

Specification:

Configuration:

Application:

External suspension components

N2TC-F640

The FLIR Duo Pro R system comprises a visible camera imager and a thermal longwave infrared imager. The visible imager has a 4000 x 3000 pixel array with a pixel pitch of 2.8um, a 6.4mm diagonal sensor, and a 4mm f/2.8 fixed focus lens. The visible camera lens is focused at infinity, and objects closer than approximately 10 meters will appear out-of-focus. Focus position of the visible camera cannot be changed. The field of view of the visible sensor is 56° x 45° (horizontal x vertical), and the lens has a maximum distortion of 15.7% and a BFL of 10.02mm. The LWIR core is based on FLIR’s Tau2 camera core. It has a 17um pixel pitch and comes in either

a 336x256 or 640x512 pixel array. Lens options and their corresponding fields of view are listed in Table 1.

640 x 512 336 x 256

13 mm: 45° x 37° 9 mm: 35° x 27°

19 mm: 32° x 26° 13 mm: 25° x 19°

25 mm: 25° x 20° 19 mm: 17° x 13°

Table 1. Duo Pro R Lens Options (FOV is Horizontal x Vertical)

N2TC-R

N2TC-R: High-resolution thermal imaging and visible light dual-lens camera For small drones

N2TC-R can convert various flight platforms into industrial tools, expanding its value and use. It is a powerful dual sensor thermal imaging and visible light camera designed for a wide range of high-performance commercial, industrial and public safety drone applications. It integrates thermal imaging and a high-definition 12-megapixel color camera in one housing. N2TC-R allows professional operators to capture thermal imaging and visible light data in flight.

In addition to its excellent imaging performance, N2TC-R can also be connected to GPS signals. These GPS information can create accurate maps and 3D models for the airborne platform, providing important data needed. The temperature measurement type N2TC-R can measure the temperature of infrared images in real time. The RAW sequence captured by the camera also contains temperature information. After shooting, the infrared image can be re-measured. It is suitable for power detection and house structure. Specific use such as inspection and fire command.

In a sturdy housing, a high-resolution thermal imager and a 12-megapixel visible light camera are installed

Simultaneously capture video and pictures of thermal imaging or visible light to improve the ability to analyze each scene.

An onboard camera that integrates both thermal imaging and visible light detectors and can be used for recording

9- 16V DC wide voltage input

The picture-in-picture technology of dual-light images can make the captured images more detailed

Real-time analog video output

Integrated thermal imaging and visible light machine synchronization recording function

Dual TF cards simultaneously record thermal imaging and visible light photos, videos, and thermal imaging lossless digital sequences.

The camera records dual-light photos and videos to the TF card synchronously according to the PWM signal, and can simultaneously record lossless 14bit infrared image sequences (RAW format)

The RAW sequence captured by the temperature measurement version N2TC-R contains temperature information, which can be used to repeatedly measure the temperature on the ground for power line inspection, fire inspection, remote sensing mapping and other applications

The camera can receive GPS data, which can be used as a reference for the pictures taken for later analysis and synthesis of maps and 3D modeling

Flexible and powerful camera control and configuration options

A variety of thermal imaging detector resolutions and infrared lenses are available to provide the best configuration for your task

The PWM signal can control the functions of the camera: thermal imaging palette switching, start/stop recording, picture-in-picture switching, etc. (specific functions can be configured)

Configurable firmware mode, so that the camera has the latest functions and features at any time.

Find out building problems, such as roof water and insulation damage

Provide dual-light images for reference in the construction of solar power plants

N2TC-R is a valuable tool for geographic surveying and other remote sensing detection.

Specification

N2GC-A640

N2GC-A640: Dual lens gimbal (30X) l Dual lens Visible 30x optical zoom lens 25mm Infrared Light Camera l HD Visible 1080p HD recording and output Infrared Light Camera resolution is 640*480 l High stability Jitter Angle: ±0.008° l One-key to center Double-click the target, center zoom function l GPS information record Superimpose GPS information display and save to subtitle file (need to be used with designated flight controller or customer's own development) l Available SDK Sky data interface and ground station SDK is available l Object Tracking

NGC-BS20: 20 million pixels gimbal

l Interchangeable lens

Sony E mount, supports fixed focus and zoom lenses

l High pixel large size sensor

APS format 20 million pixels

l High stability

Jitter Angle: ±0.008°

l One-key to center

Double-click the target, center zoom function

l GPS information record

Superimpose GPS information display and save to EXIF information

l Available SDK

Sky data interface and ground station SDK is available

l Object Tracking

Remote controller

1080P digital HD image transmission

NIRC10-3HDS integrated digital image transmission system, supports HDMI and network port two video source input, supports more video devices such as cameras, PTZ, pods, built-in HD FPV APP, supports video floating window function, can be displayed on any ground station APP Image, support video window scaling of any size, support the original QGroundControl video display function, open the video SDK for video integrated development.

Ultra long transmission distance

Using the new long-distance image transmission system, with the latest anti-interference radio frequency algorithm, the image remote control distance is as far as 10km (NIRC15-3HDS can reach to 15km), allowing you to explore a wider space without worrying about the flying distance during flight operations.

Industrial equipment level protection

Unmanned aerial vehicles work in harsh outdoor conditions. The NIRC10-3HDS is protected from dust and splashes on the fuselage, control switches, and peripheral interfaces to ensure stable and smooth operation of the equipment in harsh environments.

Highlight HD display

The 5.5-inch high-brightness high-definition display can clearly view real-time display information under strong light conditions.

Removable high-performance lithium battery

The high-performance lithium battery, low internal resistance, 6 hours long battery life, and stable battery curve provide stable power for the iUAV OS system, and can quickly replace the battery to ensure continuous operation.
